齒輪箱RA-C
機床刀庫用齒輪箱（軸回轉型）
是將精密減速機以針對方便機床廠商使用為前提而改良後的齒輪箱。高精度輸出，外殼可旋轉，使其在ATC刀庫、ATC臂、APC 刀塔部位被廣泛採用。在上述用途以外也和RD系列一樣作為精密減速機齒輪箱來應用。
產品特點
- 緊湊化
- 外殼可回轉
- 背隙在1分以內
- 空程在1分以內
- 主軸承內置
- 附帶對應各公司的伺服電機安裝連接件
- 已裝入潤滑脂
應用實例
規格
| 型號 |
|---|
| RA-20EC |
|---|
| RA-20EC |
| RA-20EC |
| RA-20EC |
| RA-20EC |
| RA-40EC |
| RA-40EC |
| RA-40EC |
| RA-40EC |
| RA-80EC |
| RA-80EC |
| RA-80EC |
| RA-80EC |
| RA-160EC |
| RA-160EC |
| RA-160EC |
| RA-160EC |
| RA-160EC |
| 額定轉矩 (kw) |
減速比 | 減速比 | 額定轉矩 （N・m） |
啟動、停止容許轉矩 （N・m） |
額定輸出轉速 （r.p.m.） |
額定壽命 （hr） |
齒隙 (arc.min.) |
空程 (arc.min.) |
扭轉剛度 (Nm/arc.min.) |
力矩剛度 (Nm/arc.min.) |
慣性力矩 (kg・m^2) |
重量 (kg) |
容許力矩① (N・m) |
|---|
| 0.375 | 81 | 81 | 167 | 412 | 15 | 6,000 | less than 1 | less than 1 | 49 | 372 | 0.00000607 | 9.5 | 882 |
| 0.375 | 105 | 105 | 167 | 412 | 15 | 6,000 | less than 1 | less than 1 | 49 | 372 | 0.00000432 | 9.5 | 882 |
| 0.375 | 121 | 121 | 167 | 412 | 15 | 6,000 | less than 1 | less than 1 | 49 | 372 | 0.00000356 | 9.5 | 882 |
| 0.375 | 141 | 141 | 167 | 412 | 15 | 6,000 | less than 1 | less than 1 | 49 | 372 | 0.00000288 | 9.5 | 882 |
| 0.375 | 161 | 161 | 167 | 412 | 15 | 6,000 | less than 1 | less than 1 | 49 | 372 | 0.00000239 | 9.5 | 882 |
| 0.924 | 81 | 81 | 412 | 1,029 | 15 | 6,000 | less than 1 | less than 1 | 108 | 931 | 0.000022 | 20 | 1,666 |
| 0.924 | 105 | 105 | 412 | 1,029 | 15 | 6,000 | less than 1 | less than 1 | 108 | 931 | 0.0000163 | 20 | 1,666 |
| 0.924 | 121 | 121 | 412 | 1,029 | 15 | 6,000 | less than 1 | less than 1 | 108 | 931 | 0.0000137 | 20 | 1,666 |
| 0.924 | 153 | 153 | 412 | 1,029 | 15 | 6,000 | less than 1 | less than 1 | 108 | 931 | 0.0000101 | 20 | 1,666 |
| 1.758 | 81 | 81 | 784 | 1,960 | 15 | 6,000 | less than 1 | less than 1 | 196 | 1,176 | 0.00006 | 27 | 2,156 |
| 1.758 | 101 | 101 | 784 | 1,960 | 15 | 6,000 | less than 1 | less than 1 | 196 | 1,176 | 0.0000482 | 27 | 2,156 |
| 1.758 | 121 | 121 | 784 | 1,960 | 15 | 6,000 | less than 1 | less than 1 | 196 | 1,176 | 0.0000396 | 27 | 2,156 |
| 1.758 | 153 | 153 | 784 | 1,960 | 15 | 6,000 | less than 1 | less than 1 | 196 | 1,176 | 0.0000298 | 27 | 2,156 |
| 3.517 | 81 | 81 | 1,568 | 3,920 | 15 | 6,000 | less than 1 | less than 1 | 392 | 2,940 | 0.000177 | 59 | 3,920 |
| 3.517 | 101 | 101 | 1,568 | 3,920 | 15 | 6,000 | less than 1 | less than 1 | 392 | 2,940 | 0.00014 | 59 | 3,920 |
| 3.517 | 129 | 129 | 1,568 | 3,920 | 15 | 6,000 | less than 1 | less than 1 | 392 | 2,940 | 0.000106 | 59 | 3,920 |
| 3.517 | 145 | 145 | 1,568 | 3,920 | 15 | 6,000 | less than 1 | less than 1 | 392 | 2,940 | 0.000087 | 59 | 3,920 |
| 3.517 | 171 | 171 | 1,568 | 3,920 | 15 | 6,000 | less than 1 | less than 1 | 392 | 2,940 | 0.000074 | 59 | 3,920 |
下載
RA-C
系列
- Selection Table of Model Code
齒輪箱
精密減速機RV中已封入油脂，可與各種主要電機連接，有3種不同輸入模式。
